Types of patchcords

Patchcords: Variety of styles for efficient networking

Patch cords (or network cables) are critical components in network systems that provide connectivity between various active network devices such as switches, routers, and servers. They are available in various types, each of which is designed for specific conditions and tasks.

Place of installation:

• External optical patch cord:It is intended for use in external networks or on the street. It is important to note that this type of network cable stands out for its extraordinary resistance to environmental influences, including weathering and humidity. Its connectors and shell provide additional protection against dust, moisture and UV radiation.

• Internal patch cord:They are used in internal networks, whether in office buildings or home premises. They play an irresistible role in the sustainable functioning of local area networks (LANs), tightly integrating computers, smartphones, tablets and other devices with high-performance routers and switches. Thanks to them, each user receives a reliable and fast connection to the entire set of resources and information on a network scale, which greatly facilitates everyday tasks and provides comfortable interaction with the Internet world. Internal network cables can be color-coded for ease of identification, helping to organize them in structured network systems.

Connection form:

• Corner patchcord: Used in situations where access to network equipment ports is limited. This particular type of cable is equipped with a special angled connector at one or both ends, which allows you to establish a connection at a right angle (90 degrees). This innovative solution reduces the load on the ports of the equipment, which is an important aspect of ensuring an efficient and secure Internet connection.
• Straight patchcord:It is a regular cable in which the wires at the ends are arranged in the same way according to the pinout (wiring 1: 1). It is used to connect different devices with the same port structure.

Types of network cable depending on the category:

Another important characteristic is the wire category, which determines its bandwidth and data transfer capabilities. There are different categories of cables such as Cat5e, Cat6, Cat6a and Cat7, and each of them has its own features and applications.

• Cat5e provides speeds up to 1000 Mbps and is suitable for most office networks and home networks.
• Cat6 is capable of delivering speeds up to 10 Gbps over distances up to 55 meters and is often used in gigabit networks.
• Cat6a also supports speeds up to 10Gbps, but over longer distances (up to 100 meters), making it ideal for larger enterprises.
• Cat7, with its impressive bandwidth, is capable of rapidly transmitting data at speeds up to 10 Gbps at distances up to 100 meters, making it an indispensable choice for today's high-speed networks. In addition, it provides additional shielding to reduce interference.

Filtered patch cord:

They are also known as "shielded". They have an additional shielding layer that prevents external noise from affecting the signals in the cable. This is especially important in areas with high levels of electromagnetic interference or near other electrical devices.

So,Choosing the right patch cord type and wire category can improve your network performance and minimize possible connection problems. When choosing a cable, it is recommended that you use only trusted manufacturers, such as Ipcom, to ensure high quality and reliability of products.
